Hluav taws xob & Electronics Txhaj Moulds

Kev cai Txhaj Moulds rau cov khoom siv hluav taws xob & hluav taws xob

Hluav taws xob thiab hluav taws xob txhaj tshuaj pwm xav tau kev tswj hwm nruj ntawm qhov ntim ntim, cov kab sib cais, thiab kev tswj xyuas thermal kom tsis txhob muaj teeb meem ntawm cov ntu nyias thiab tswj cov rwb thaiv tsev clearances. SUNJOY xa cov cuab yeej kev cai rau cov khoom siv hluav taws xob, cov khoom siv hluav taws xob ntse, cov khoom siv hluav taws xob, thiab cov khoom siv hluav taws xob hauv tsev.

Moulds yog tsim los ua kom haum rau cov resin shrinkage tus nqi - suav nrog cov khoom siv hluav taws xob xws li PA6 / PA66 (30 feem pua GF), PC, PC / ABS, PBT, thiab nplaim taws- cov qib retardant raws li UL94 V-0 cov qauv. Gating systems, venting layouts, thiab ejection mechanisms yog tailored ncaj qha mus nias tonnage thiab automated los ua ke kab.

Core Engineering Advantages

Tight Dimensional Control

Qhov tseem ceeb ua haujlwm qhov ntev tuav nyob rau hauv ntxiv rau- rho tawm 0.02 mm kam rau ua qhov txwv, kom ntseeg tau tias tsis muaj seamless snap- haum sib dhos thiab xoom- qhov sib txawv hauv ntau- ib feem hauv vaj tsev.

Optimized Thermal Management

Conformal cooling channels thiab Beryllium Copper inserts siv nyob rau hauv siab - tshav kub zones, txo lub sij hawm mus txog rau 25 feem pua thiab txo cov warpage ntawm ca npog.

Parting Kab Integrity

Precision CNC machining thiab optical comparator txuam tshem tawm flash ntawm connector pins thiab sab nrauv, txo cov phau ntawv trimming.

Traceable Tool Steels

Daim ntawv tshaj tawm cov khoom siv ncaj qha (MTR) muab rau txhua qhov tseem ceeb, kab noj hniav, thiab pwm hauv paus steels, kom ntseeg tau tias qhov kev kho cua sov ua kom tawv thiab cov cuab yeej siv tau ntev.

Product Range & Applications Coverage

Sub-Qeb	Tej kev siv	Common Resins	Ntsiab Engineering Focus
Hluav taws xob enclosures	Circuit Court breaker thawv, 'meter' vaj tse, faib boards	ABS, PC/ABS, SMC/BMC, Nplaim-Retardant PC	Cov qauv rigidity, phab ntsa thickness uniformity, UL94 ua raws
Connectors & Terminals	Terminal blocks, multi-pin vaj tse, relay bases	PBT (30 feem pua GF), PA66, LCP	Zero flash, micro-features, dimensional stability
Consumer Electronics	Fais fab adapter plhaub, router tsev, LED tsav tsheb rooj plaub	PC, ABS, HIPS	High-gloss tiav, dab ntxuav tes tshem tawm, snap- haum durability
Smart Home Hardware	Hloov cov panels, sensor npog, thermostat casings	PMMA, PC, ABS	Clear qhov rais polishing, kev ntxhib los mos txuam (MT tus qauv)

Tooling Manufacturing Workflow

DFM & Moldflow Analysis:Kev tshuaj xyuas engineering txheeb xyuas cov kaum sab xis, cov cim dab dej, cov kab txuas, thiab qhov rooj qhov rooj ua ntej txiav steel.

High -Precision Machining:Multi-axis CNC milling, siab-ceev nyuaj milling, thiab xaim EDM tswj kev kam rau siab mus rau ntxiv - rho tawm 0.005 hli.

EDM & Daim iav Polishing:Precision sinking EDM rau cov ces kaum sab hauv; phau ntawv tes polishing mus txog SPI A1 lossis SPI A2 tiav rau thaj chaw kho qhov muag.

Sib dhos & Fit-Up:Mechanical haum ntawm cores, kab noj hniav, slides, lifters, thiab kub khiav manifolds nyob rau hauv nruj clearance xyuas.

T1 sim & Sampling:Kev sim pwm thawj zaug ntawm cov xovxwm tshwj xeeb siv cov neeg siv khoom-cov ntaub ntawv tshwj xeeb, ua raws li 3D CMM tshuaj xyuas.

Quality Control & Metrology

Dimensional verification raws tu qauv siv los ntawm raw cov ntawv txais steel mus rau qhov kawg crate packing:

Steel Hardness Test:Rockwell (HRC) thiab Leeb qhov kev ntsuam xyuas hardness ua rau txhua qhov tseem ceeb thiab kab noj hniav thaiv ncej- kho cua sov.

CMM Dimensional Inspection:Hexagon CMM pov thawj ntawm profile, txoj hauj lwm, thiab qhov tseem ceeb ua haujlwm qhov ntev ntawm molded T1 qauv.

Hot Runner Verification:Hluav taws xob tsis kam, thermocouple continuity, thiab thermal tshuav nyiaj li cas ntawm manifold systems.

Inspection Deliveables:Daim Ntawv Qhia Txog Kev Tshawb Fawb Tag Nrho, CMM cov ntaub ntawv, Daim Ntawv Pov Thawj Cov Khoom Siv, thiab Pwm Parameter Sheet muab khoom xa tawm.

Customization & Engineering Support

Cov cuab yeej tsim nruj raws li kev tsim khoom thiab cov qauv cog:

Txheem Compatibility

Cov cuab yeej ua rau HASCO, DME, lossis LKM tus qauv raws li kev nyiam saib xyuas.

Kub khiav kev koom ua ke

Qhib lossis valve- rooj vag kub khiav teeb tsa kom tshem tawm cov rooj vag vestiges ntawm cov khoom siv hluav taws xob pom.

Interchangeable Inserts

Ceev-hloov cov ntsiab lus ntxig rau hauv cheeb tsam sib txawv lossis cov cim ntsuas hluav taws xob.

Kev lag luam kev siv

SUNJOY hluav taws xob thiab hluav taws xob pwm tau siv thoob ntiaj teb thoob plaws plaub qhov chaw uas muaj kev ntseeg siab thiab kev nyab xeeb yog qhov tseem ceeb:

Kev faib hluav taws xob muaj zog

Cov cuab yeej kev cai rau lub thawv hluav taws xob hluav taws xob, hnyav- lub luag haujlwm hloov khoom siv hluav taws xob, cov khoom siv hluav taws xob, thiab cov khoom siv hluav taws xob relay ua haujlwm hauv kev lag luam thiab kev lag luam hluav taws xob.

Ntse Metering & Infrastructure

Precision pwm rau cov khoom siv hluav taws xob hauv tsev ntse, kev sib txuas lus davhlau ya nyob twg blocks, sensor casings, thiab kev sib txuas lus network kho vajtse.

Consumer Electronics & Adapters

High-cov cuab yeej ua tau zoo rau lub hwj chim adapter plhaub, cov vaj tse me me, cov khoom siv hluav taws xob LED, thiab cov txheej txheem sab hauv uas yuav tsum tau nruj snap- haum haum.

Cov Khoom Siv Hauv Tsev Ntse

Ntau-kab kab noj hniav pwm rau dawb- cov khoom tswj vaj huam sib luag, cov khoom siv ntsuas kub, cov npog pob tshab, thiab cov tsev tshwj xeeb nrog siab -gloss zoo nkauj yuav tsum.

Vim li cas thiaj xaiv SUNJOY Pwm

Direct Chaw Tsim Khoom

Hauv - lub tsev cov cuab yeej cuab tam tau nruab nrog 15+ CNC chaw, EDM cov cav tov, thiab cov kev sim siab. Tsis muaj outsourced tool brokerage.

Transparent Engineering Communication

Kev nkag ncaj qha rau tus thawj tswj hwm qhov project thiab cov cuab yeej cuab yeej ua haujlwm muab cov kev daws teeb meem DFM.

Pov thawj Export Reliability

Tshaj li 12 xyoos ntawm kev muab kev txhaj tshuaj pwm rau tier-1 chaw tsim khoom thoob plaws North America thiab Europe.

Export Ntim & Logistics Txhawb nqa

Export ntim raws li nruj thoob ntiaj teb shipping qauv:

Anti-xeb tshuaj tsuag thiab cov dej tsis muaj dej nqus cov ntawv qhwv siv rau kev sib dhos ua tiav pwm.

ISPM 15 raws li fumigated ntoo crates ruaj ntseg nrog cov bracing blocks los tiv thaiv kev hloov.

Cov khoom siv dav dav: Cov khoom siv khoom seem (piv txwv li, ejector pins, springs), 2D / 3D CAD kos duab (STEP), kab kos duab, thiab T1 sim parameter cav.

Cov lus nug nquag

Q: Koj ua li cas txog kev tshuaj xyuas DFM rau cov phiaj xwm hluav taws xob tshiab?

A: Thaum tau txais 3D CAD cov ntaub ntawv (STEP / IGES) thiab 2D kos duab, peb pab pawg ua haujlwm ua haujlwm 48-teev tshuaj xyuas. Peb txheeb xyuas cov kaum sab xis, phab ntsa thickness uniformity, qhov rooj nkag, thiab cov cim dab dej, muab cov lus piav qhia ua ntej txiav cov hlau.

Q: Lub sij hawm ua tus qauv ntawm qhov project kickoff rau T1 qauv xa khoom yog dab tsi?

A: Cov cuab yeej txheem tsim lub sijhawm txij li 35 txog 55 hnub ua haujlwm, nyob ntawm qhov loj me, kab noj hniav suav, thiab qhov nyuaj. Complex kub khiav tshuab los yog cov txheej txheem loj (800T + xovxwm yuav tsum tau) yuav tsum tau 55 mus rau 65 hnub. Lub sijhawm tseem ceeb yog tsim los ntawm kev tshaj tawm PO.

Q: Koj yuav txheeb xyuas qhov tseeb li cas ua ntej xa cov pwm?

A: Peb khiav T1 kev sim siv cov qib cob qhia thiab tshuaj xyuas cov qauv pwm siv Hexagon CMM los txheeb xyuas qhov tseem ceeb ntawm qhov ntev thiab phab ntsa tuab. Pwm nkoj tsuas yog tom qab CMM daim ntawv tshaj tawm thiab kev pom zoo ua qauv.

Q: Koj puas tuaj yeem koom ua ke cov npe kub khiav rau hauv pwm tsim?

A: Yog. Peb niaj hnub koom ua ke thoob ntiaj teb hom xws li Yudo, Incoe, Synventive, thiab Husky raws li cov qauv kev saib xyuas cov nroj tsuag thiab cov khoom seem ntawm cov khoom nyiam.

Q: Cov ntaub ntawv dab tsi thiab cov khoom seem tau muab nrog cov pwm xa tawm?

A: Txhua pwm suav nrog cov khoom siv khoom seem (xws li, ejector pins, springs), 2D / 3D engineering kos duab hauv STEP / PDF, phau ntawv kub khiav thiab cov kab kos duab, daim ntawv pov thawj steel, thiab daim ntawv qhia txog kev soj ntsuam CMM.

Raws li ib qho ntawm cov ua hluav taws xob & hluav taws xob txhaj tshuaj pwm manufacturers thiab cov muag khoom nyob rau hauv Suav teb, peb sov siab txais tos koj mus yuav customized hluav taws xob & hluav taws xob txhaj tshuaj pwm ua nyob rau hauv Suav teb nov los ntawm peb lub hoobkas. Cov kev pabcuam zoo thiab cov khoom zoo yog muaj.
